| Product Name: ASA 5520 VPN/Firewall |
| Product Type: VPN/Firewall |
| |
| |
| Number of Ports: 5 |
| Interfaces/Ports: 1 x RJ-45 Auxiliary Management |
| Interfaces/Ports: 4 x RJ-45 1000Base-T |
| Interfaces/Ports: 1 x RJ-45 10/100Base-TX |
| Interfaces/Ports: 2 x USB USB 2.0 |
| Interfaces/Ports: 1 x RJ-45 Console Management |
| |
| |
| Manufacturer: Cisco Systems, Inc |
| Brand Name: Cisco |
| Product Line: ASA |
| Product Series: 5500 |
| |
| |
| Virtualization: 750 Web VPN Peers |
| Virtualization: 2 Security Contexts |
| Virtualization: 2 Web VPN Peers |
| Virtualization: 750 IPSec VPN Peers |
| Virtualization: 150 |
| Virtualization: 9000 Concurrent Sessions |
| Virtualization: 20 Security Contexts |
| Virtualization: 280000 Concurrent Sessions |
| Firewall Protection: Intrusion Prevention |
| Firewall Protection: Worm Scanning |
| Firewall Protection: Malware Protection |
| Firewall Protection: Antivirus |
| Encryption Standard: AES |
| Encryption Standard: 3DES |
VPN Support:
- IPSec/SSL VPN
- VPN clustering and load balancing
- IPSec/SSL VPN
- VPN clustering and load balancing
|
| License Type: ASA 5500 VPN Base License |
| License Type: ASA 5500 Encryption License |
| |
| |
| VPN Throughput: 225Mbps |
| Firewall Throughput: 450 Mbps |
| |
| |
| Number of Expansion Slots: 2 |
| Expansion Slots: (1 Total) CompactFlash (CF) Card |
| Expansion Slots: (1 Total) SSM |
| |
| |
| Protocols: IPSec |
| Protocols: TCP/IP |
| Management:
Web-based management |
| |
| |
| Processor: Intel Celeron 2GHz |
| |
| |
| Standard Memory: 512 MB |
| Memory Technology: DRAM |
| Flash Memory: 64 MB |
| |
| |
| Status Indicators:
Front Panel LEDs:
- MGMT indicator LEDs
- Network interface LEDs
- Power
- Status
- Active
- VPN
- Flash
Rear Panel LEDs:
- 2 x Power indicator
- Status Indicator
- Active
- VPN
- Flash
- AUX
|
| |
| |
| Power Consumption: 150 W Standard |
| Power Consumption: 190 W Maximum |
| |
| |
| Temperature: 0 degrees C (32.0 degrees F) to 40 degrees C (104.0 degrees F) Operating |
| Temperature: -25 degrees C (-13.0 degrees F) to 70 degrees C (158.0 degrees F) Non-operating |
| Humidity: 5 to 95% Non-condensing Relative Humidity Non-operating |
| Humidity: 5 to 95% Non-condensing Relative Humidity Operating |
| Altitude: 0 ft to 14993.44 ft - Non-operating |
| Altitude: 0 ft to 9842.52 ft - Operating |
| Thermal Dissipation: 648 BTU/h |
| |
| |
| Compatible Rack Unit: 1U |
| Form Factor: Rack-mountable |
| Form Factor: Desktop |
| Dimensions: 1.75 Height x 17.5 Width x 13.2 Depth |
| Weight: 20 lb |
| |
| |
| Additional Information:
High Availability:
- Active/Active
- Active/Standby
|
| Certifications & Standards:
|
